ALU-bunks

Light and strong full aluminium bunks that guarantee maintenance free and economical timber transport. ALU 95 is additionally suitable for a 2/4 bunk combination.

The weights in our ALU- series varies according to stake length between 87-133 kg per bunk including two stakes but not bunkfixings. Telescopic stakes can be installed on a height between 2 200-3 300 mm.

ALU 55

ALU 55 represents 5-ton bunk. This is the lightest model of bunks in order to benefit from maximum timber loads.

Material Anodised 6000 and 7000 -series aluminium
Weight from 87 kg + pair of fixings 28 kg
Bunkframe lenght 2 550 mm or 2600 mm
Bunkframe height 175 mm
Stake length max. 3000 mm
Downloads

ALU 75 -bunk

ALU 75 represents 7-ton bunk. Most practical and really reliable bunk for timber transportation.

Material Anodised 6000 and 7000 -series aluminium
Weight from 104 kg + pair of fixings 28 kg
Bunkframe lenght 2 550 mm or 2 600 mm
Bunkframe height 180 mm
Stake length max 3 300 mm
Downloads

ALU 95 -bunk

ALU 95 represents 9-ton bunk and is additionally suitable for a 2/4 bunk combination.



Material Anodised 6000 and 7000 -series aluminium
Weight from 120 kg + pair of fixings 28 kg
Bunkframe lenght 2 550 mm or 2 600 mm
Bunkframe height 185 mm
Stake length max 3 300 mm
Downloads

Features of ALU -bunks

Design

Modern and finished outlook with strong bunk frame. ALU series are not stressed of corrosion and the qualified surface treatment makes the bunks easy to clean.

Technology

Easy and quick installation to whatever truck and trailer. Reliable bolt connections.

Practicality

Detachable stakes make the service work wasy and all models are available with fixed lenght staeks and extendable stakes. The conical stake can be inside or outside. We can also attach lights on top of the stakes. Alu-bunks have a long life-time!

Latest Made in Maxmo with ALU bunks

Want to know more? Contact us

Ask more information from us
